Backyard Discovery BEACH FRONT - Page 17

E7
E7 - MONKEY BAR RAIL - W4L06938
1
3/8"x3 3/8"x48" (36x86x1219)
(1)
SB - TRIANGLE PLATE BLUE 100 5 HOLE - A100309
(1)
MONKEY BAR ASSEMBLY
STEP 2
BOLT WH
5
/16x1 1/2
(3)
T-NUT 5/16
(3)
T-NUT 5/16
(3 PLCS)
BOLT WH 5/16x1 1/2
(3 PLCS)
TRIANGLE PLATE BLUE 100 5 HOLE
BOLT WH 5/16x1
WASHER LOCK EXT 8x19
L BRACKET BLUE 2.5x38x50x55
NUT BARREL WH 5/16x7/8
- L BRACKET BLUE 2.5x38x50x55 - A4M00584
(1)
WASHER
L
OCK EXT
8x19
(1)
NUT BARREL
WH 5/16x7/8
(1)
BOLT WH
5
/16x1
(1)
