Backyard Discovery BEACH FRONT - Page 19

MONKEY BAR ASSEMBLY
STEP 4
T-NUT 5/16
(2)
WASHER
LOCK INT
8x15
(2)
WASHER
FLAT 9x18
(2)
SCREW
TAPPING
14x1-1/2
(2)
BOLT WH
5
/16x1 1/2
(2)
E5 - MONKEY BAR UPRIGHT - W4L06964
1 3/8"x3 3/8"x70 3/8" (36x86x1786)
(1)
- HAND GRIP LIME PLASTIC - A6P00127
(1)
BOLT WH 5/16x1 1/2
(2 PLCS)
T-NUT 5/16
(2 PLCS)
SCREW TAPPING 14x1-1/2
(2 PLCS)
WASHER LOCK INT 8x15
(2 PLCS)
HAND GRIP LIME PLASTIC
WASHER FLAT 9x18
(2 PLCS)
