BENCH ASSEMBLY
STEP 3
SCREW PFH
8x1 3/4
(8)
SCREW PFH 8x1 3/4
(8 PLCS)
H9
H9
H9 - BENCH SEAT SUPPORT - W4L06969
1"x3 3/8"x6 1/2" (24x86x166)
(2)
FLUSH TO TOP.
