STEP 5
J1
FLUSH O1 BOARDS
TO TOP OF
J1 BOARD.
O1
3 1/16"
TYPICAL SPACING
SCREW PFH
8x1 1/8
(14)
SCREW PFH 8x1 1/8
(14 PLCS)
O1 - PICKET - W4L06901
5
/8"x1 3/8"x13 1/4" (16x34x336)
(7)
