Backyard Discovery BEACH FRONT - Page 38

STEP 7
LAG SCREW
WH 5/16x2
(1)
LAG SCREW
W
H 1/4x1-1/2
(2)
LAG SCREW
WH 5/16x1 1/2
(3)
WASHER
LOCK EXT
6x15
(2)
WASHER
LOCK EXT
8x19
(4)
M5
M2
J6
M2 - FLOOR RAIL - W4L06897
5
/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
J6 - LADDER RAIL - W4L06910
1"x2 3/8"x50 1/8" (24x60x1273)
(1)
M5 - FLOOR RAIL - W4L06914
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
LAG SCREW WH 5/16x1 1/2
(3 PLCS)
WASHER LOCK EXT 8x19
(3 PLCS)
LAG SCREW WH 5/16x2
WASHER LOCK EXT 8x19
LAG SCREW WH 1/4x1-1/2
(2 PLCS)
WASHER LOCK EXT 6x15
(2 PLCS)
NOTE HOLE LOCATION.
NOTE HOLE
LOCATIONS
CLOSER TO
J6 BOARD HOLE
LOCATION.
