STEP 10
J9
J9
J9
J9
SCREW PFH
8x1 3/4
(8)
SCREW PFH 8x1 3/4
(8 PLCS)
M2
M5
J9 BOARDS
ARE FLUSHED
WITH THE TOP
OF M2 AND M5
BOARDS.
J9 - SUPPORT BOARD - W4L06064
1
"x2 3/8"x3" (24x60x76)
(4)
