Backyard Discovery BEACH FRONT - Page 46

STEP 15
K6
J7
BOLT WH
5
/16x1 1/2
(2)
BOLT WH
1
/4x1/2
(2)
WASHER
LOCK EXT
8x15
(2)
NUT BARREL
WH 1/4x5/8
(2)
WASHER
LOCK EXT
8x19
(3)
T-NUT 5/16 (2)
K6 - GROUND BOARD - W4L06904
5
/8"x5 1/4"x44 1/2" (16x134x1129)
(1)
J7 - LADDER RAIL - W4L06911
1"x2 3/8"x50 1/8" (24x60x1273)
(1)
BOLT WH
5/16x1
(1)
NUT BARREL WH 1/4x5/8
(2 PLCS)
WASHER LOCK EXT 8x15
(2 PLCS)
BOLT WH 1/4x1/2
(2 PLCS)
BOLT WH 5/16x1
WASHER LOCK EXT 8x19
BOLT WH 5/16x1 1/2
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
T-NUT 5/16
(2 PLCS)
BACK VIEW
90° L-BRACKET - BLK
K6
J7
- 90° L-BRACKET - BLK - A4M00555
(1)
