Backyard Discovery BEACH FRONT - Page 55

STEP 24
H4
H5
H4
H5
BOLT WH
5
/16x2 1/4
(4)
WASHER
L
OCK EXT
8x19
(4)
T-NUT 5/16 (4)
SCREW PFH
8x2
(8)
H4 - HORIZONTAL TARP SUPPORT - W4L06946
1
"x3 3/8"x56 1/8" (24x86x1425)
(2)
H5 - HORIZONTAL TARP SUPPORT - W4L06949
1"x3 3/8"x48 3/4" (24x86x1237)
(2)
BOLT WH 5/16x2 1/4
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
T-NUT 5/16
(4 PLCS)
SCREW PFH 8x2
(8 PLCS)
NOTE:
H5 PILOT HOLES
ARE UPWARD.
