Backyard Discovery BEACH FRONT - Page 61

STEP 30
M3
M4
LIME HC ROCK #1
CRANBERRY HC ROCK #1
BLUE HC ROCK #2
BOLT PTH
1
/4x3/4
(12)
WASHER
L
OCK INT
8x15
(12)
T-NUT 1/4
(12)
M4 - LADDER RUNG - W4L06913
5
/8"x3 3/8"x20 1/4" (16x86x515)
(6)
- LIME HC ROCK #1 - A6P00128
(2)
- BLUE HC ROCK #2 - A6P00040
(2)
- CRANBERRY HC ROCK #1 - A6P00129
(2)
BOLT PTH 1/4x3/4
(12 PLCS)
WASHER LOCK INT 8x15
(12 PLCS)
T-NUT 1/4
(12 PLCS)
NOTE:
PLACE THE ROCKS
AND HARDWARE
ONTO THE M4 BOARDS
BEFORE PLACING
ON J6 AND J7 BOARDS.
J7
J6
SCREW PFH
8
x1 1/4
(28)
M3 - LADDER RUNG - W4L06912
5
/8"x3 3/8"x20 1/4" (16x86x515)
(1)
SCREW PFH 8x1 1/4
(28 PLCS)
