Phase Notes
• Assemble with hardware as shown.
Parts needed:
• (1) KB - PICNIC TABLE TARP - A100195
Fort Assembly
Phase 15
Hardware needed:
• (6) CY - SCREW PWH 8x5/8 - H100128
Step 1:
Drape 'KB' Tarp over 'M4' floor / tarp
support and 'M3' tarp supports. Attach one side of
tarp to the inside of 'M3' with (3) Screws 'CY'. Pull
other side of tarp tight and attach to the inside of
'M4' tarp support using (3) Screws 'CY', as shown.
KB
M4
M3
KB
CY
CY
