Backyard 720-0783B - Parts List

Parts List
9
11Side Shelf Control Panel, Right37
11Manual7311Pulse Igniter Module36
11K/D Hardware pack7211Side Burner Gas Valve, Right35
11Tank Tray Bolt7111Side Burner Bowl Assembly,
Right
34
11Tank Tray7011Side Burner Cooking Grid, Right33
21Gas Tank Tray Slide6941Side burner lid hinge rod pin32
11Gas Tank Tray Block Piece6821Side Burner Lid Hinge Rod,
Right
31
11Gas Tank Tray Slide Bracket, Left6711Side Burner Lid, Right30
11Gas Tank Tray Slide Bracket, Right6611Grease Pan29
21Door Handle Assembly6511Grease Box28
11Lighting Rod6411Warming Rack27
11Door, Left6321Cooking Grid with Hole26
11Door, Right6241Flame Tamer25
21Door Magnet6111Main Burner Igniter Wire D24
11Cart Frame, Front6011Main Burner Igniter Wire C23
11Side Panel, Right5911Main Burner Igniter Wire B22
11Triangle Bracket, Right5811Main Burner Igniter Wire A21
11Triangle Bracket, Left5745Main Burner20
11Door iron piece5621Hood Buffer B19
21Caster55Non-
replaceable
1Main burner bowl assembly18
11Swivel Caster with Brake5411Front baffle17
11Swivel Caster5341Main Gas Valve16
11Side Panel, Left5211Regulator, LP15
11Back Panel5111Side Burner Manifold14
11Back Panel, top5011Main Manifold13
11Bottom Panel4921Side Burner Flex Gas Line12
11Side Shelf Control Panel, Left4811Sear Burner Manifold11
11Sear Burner Gas Valve4711Main Control Panel10
11Sear Burner Grease Tray4641Bezel9
11Sear Burner Bowl Assembly4561Control Knob8
11Sear Burner Igniter Wire4421Hood Buffer A7
11Sear Burner Cooking Grate4311Logo6
11Sear Burner4211Temperature Gauge Housing5
21Sear Burner Lid Hinge Rod, Left4111Temperature Gauge4
11Sear Burner Lid4041Burner Pin Assembly3
11Side Burner Igniter Wire3921Main Lid Screw2
15Side Burner Pipe3811Main Lid1
QT
Y
Warranty
coverage
(Year)
PART (Description)No.QTYWarranty
coverage
(Year)
PART (Description)No.
