September 2012 Page 7
PFM Portable Hydraulic Testers PFM6, PFM6BD, and PFM8
CALIBRATION
Testers are calibrated with a 32 cSt (150 SUS) hydraulic oil. Standard calibration is done using 5 points and is traceable to NIST,
ISO 9001. An optional 10 point calibration can be performed for increased accuracy.
SERIES/MODEL NUMBER DESIGNATIONS
SERIES MODEL NUMBER *
NOMINAL PORT
SIZE
FLOW RATE POWER HP KW
PFM6-15 F5080 (CE) - XXX SAE 12 1 - 15 GPM
N/A
PFM6-30 F5079 (CE) - XXX SAE 12 2 - 30 GPM
PFM6-60 F5078 (CE) - XXX SAE 16 3 - 60 GPM
PFM6-85 F5077 (CE) - XXX SAE 16 4 - 85 GPM
PFM6-200 F5076 (CE) - XXX SAE 24 7 - 199.9 GPM
PFM6-15 F5110 (CE) - XXX G ¾ 4 - 56 LPM
N/A
PFM6-30 F5111 (CE) - XXX G ¾ 7.5 - 113.6 LPM
PFM6-60 F5112 (CE) - XXX G 1 12 - 227 LPM
PFM6-85 F5113 (CE) - XXX G 1 15 - 321 LPM
PFM6-200 F5114 (CE) - XXX G 1½ 26 - 757 LPM
PFM6BD-60 F5082 (CE) - XXX SAE 16 3 - 60 GPM / 12 - 227 LPM
N/APFM6BD-85 F5083 (CE) - XXX SAE 16 4 - 85 GPM / 15 - 321 LPM
PFM6BD-200 F5084 (CE) - XXX SAE 24 7 - 199.9 GPM / 26 - 757 LPM
PFM8-15 F5061 SAE 12 1 - 15 GPM / 4 - 56 LPM 52.5 (39)
PFM8-30 F5058 SAE 12 2 - 30 GPM / 7.5 - 113.6 LPM 105 (78)
PFM8-60 F5052 SAE 16 3 - 60 GPM / 12 - 227 LPM 210 (157)
PFM8-85 F5053 SAE 16 4 - 85 GPM / 15 - 321 LPM 98 (222)
PFM8-200 F5054 SAE 24 7 - 199.9 GPM / 26 - 757 LPM 700 (522)
* Replace XXX with PSI, BAR, KG/CM2 or MPA to specify complete model number.
Table2: Model Number Designations
