HR-E LCD 4-20
Analog Output
• The input pulses generated within the transmitter assembly are converted to a standard 4-20 mA control signal.
• This signal is proportional to the flow of fluid passing through the flow meter.
• Power for the device can be obtained from a 9…50V DC control loop.
• The default 20mA setting of the signal is defined in the registration section.
Endpoint Reading Resolution
MPORTANTI
The standard electronic encoder output resolution of the HR-E LCD 4-20 encoder is 9 digits. Though the encoder output is 9-digit
resolution, the reading resolution sent to the reading software is dependent on the endpoint that the encoder is connected to.
Readings reported from the endpoints are the left-most significant digits of the encoder reading.
Endpoint Technology Reading Resolution Reported to Reading Software
ORION Cellular 9-digit reading, plus the extended message capability
ORION Migratable (ME)/Fixed Network (SE) 8-digit reading, plus the extended message capability
ORION Classic (CE) 7-digit reading
See the application brief, HR-E LCD Encoder Test Circle Codes, available at www.badgermeter.com, for the appropriate test circle
code/reading resolutions for the encoder with ORION endpoints. Other output options are available for certain applications.
Page 10 April 2019LCD-UM-01482-EN-07
