Badger Meter HR-E LCD User Manual

HR-E LCD 4-20
HRE LCD 420
The HR-E LCD 4-20 is a permanently sealed, electronic LCD absolute encoder which produces an industry standard ASCII
encoded output as well as a 4-20 mA DC output signal through a dual output wire design.
Measurement Resolution
Standard encoded output is 9 digits. The 4-20 signal from the encoder is proportional to the flow of fluid passing through the
meter. Power for the 4-20 output signal device can be obtained from a 9…50V DC control loop. The default 20 mA setting of
the signal is defined in the resolution chart.
Recordall Disc Series Size (in.)
Encoder Output Analog Output
9-dial (gal) 9-dial (ft
3
) 9-dial (m
3
) 20 mA Set point (gpm)
LP 5/8, 5/8 x 3/4 0.01 0.001 0.0001 20
M25 5/8, 5/8 x 3/4 0.01 0.001 0.0001 25
M35 3/4 0.01 0.001 0.0001 35
M40 1 0.01 0.001 0.0001 40
M55 1 0.01 0.001 0.0001 55
M70 1 0.01 0.001 0.0001 70
M120 1-1/2 0.1 0.01 0.001 120
M170 2 0.1 0.01 0.001 170
Recordall
Turbo Series
Size (in.)
Encoder Output Analog Output
9-dial (gal) 9-dial (ft
3
) 9-dial (m
3
) 20 mA Set point (gpm)
T160 1-1/2 0.1 0.01 0.001 200
T200 2 0.1 0.01 0.001 310
T450 3 0.1 0.01 0.001 550
T1000 4 0.1 0.01 0.001 1250
T2000 6 1 0.1 0.01 2500
T3500 8 1 0.1 0.01 4500
T5500 10 1 0.1 0.01 7000
T6200 12 10 1 0.01 8800
T6600 16 10 1 0.01 13200
T10000 20 10 1 0.01 19800
Recordall Compound
Series
Size (in.)
Encoder Output Analog Output
9-dial (gal) 9-dial (ft
3
) 9-dial (m
3
) 20 mA Set point (gpm)
High Side T200 2 0.1 0.01 0.001 200
Low Side M25 2 0.01 0.001 0.0001 25
High Side T450 3 0.1 0.01 0.001 450
Low Side M25 3 0.01 0.001 0.0001 25
High Side T1000 4 0.1 0.01 0.001 1000
Low side M35 4 0.01 0.001 0.0001 35
High Side T2000 6 1 0.1 0.01 2000
Low Side M35 6 0.01 0.001 0.0001 35
High Side T3500 8 1 0.1 0.01 —
Low side M120 8 0.1 0.01 0.001 —
Page 9 April 2019 LCD-UM-01482-EN-07
