Badger Meter HR-E LCD User Manual

HR-E LCD
HRE LCD
The HR-E LCD is a permanently sealed, electronic LCD absolute encoder which produces an industry standard ASCII
encoded output.
Measurement Resolution
Recordall
Disc Series
Size (in.)
9-Digit Encoder
Gallons Cubic Feet Cubic Meters
LP 5/8, 5/8 x 3/4 0.01 0.001 0.0001
M25 5/8, 5/8 x 3/4 0.01 0.001 0.0001
M35 3/4 0.01 0.001 0.0001
M40 1 0.01 0.001 0.0001
M55 1 0.01 0.001 0.0001
M70 1 0.01 0.001 0.0001
M120 1-1/2 0.1 0.01 0.001
M170 2 0.1 0.01 0.001
Recordall
Turbo Series
Size (in.)
9-Digit Encoder
Gallons Cubic Feet Cubic Meters
T160 1-1/2 0.1 0.01 0.001
T200 2 0.1 0.01 0.001
T450 3 0.1 0.01 0.001
T1000 4 0.1 0.01 0.001
T2000 6 1 0.1 0.01
T3500 8 1 0.1 0.01
T5500 10 1 0.1 0.01
T6200 12 10 1 0.01
T6600 16 10 1 0.01
T10000 20 10 1 0.01
Recordall Compound
Series
Size (in.)
9-Digit Encoder
Gallons Cubic Feet Cubic Meters
High Side T200 2 0.1 0.01 0.001
Low Side M25 2 0.01 0.001 0.0001
High Side T450 3 0.1 0.01 0.001
Low Side M25 3 0.01 0.001 0.0001
High Side T1000 4 0.1 0.01 0.001
Low side M35 4 0.01 0.001 0.0001
High Side T2000 6 1 0.1 0.01
Low Side M35 6 0.01 0.001 0.0001
High Side T3500 8 1 0.1 0.01
Low side M120 8 0.1 0.01 0.001
Endpoint Reading Resolution
MPORTANTI
The standard electronic encoder output resolution of the HR-E LCD encoder is 9 digits. Though the encoder output is 9-digit
resolution, the reading resolution sent to the reading software is dependent on the endpoint that the encoder is connected to.
Readings reported from the endpoints are the left-most significant digits of the encoder reading.
Endpoint Technology Reading Resolution Reported to Reading Software
ORION Cellular 9-digit reading, plus the extended message capability
ORION Migratable (ME)/Fixed Network (SE) 8-digit reading, plus the extended message capability
ORION Classic (CE) 7-digit reading
GALAXY 6-digit reading
See the application brief, HR-E LCD Encoder Test Circle Codes, available at www.badgermeter.com, for the appropriate test circle
code/reading resolutions for the HR-E LCD encoder with ORION or GALAXY endpoints. Other output options are available for
certain applications.
Page 7 April 2019 LCD-UM-01482-EN-07
