Operating Manual BaehrTec S2000
Page 48/52 English– V101 – Status 07/2015
6 Technical Data
BaehrTec S2000
Medical device
Class 2A according to EU Directive 93/42 Medical
devices
EMC test
Under EN 60601-1
Operating voltage
110 – 240 V AC voltage
Frequency
50 – 60 Hz
Micromotor speed range
6,000 – 40,000 rpm adjustable
Accuracy of the speeds
6,000 – 10,000 rpm, tolerance +/- 20 %
10,000 – 40,000 rpm, tolerance +/- 10 %
Power consumption
Max. 80 watts
Micromotor voltage
24 V
Working voltage
28 V
Controller dimensions (W x D x H) in mm
(without handpiece
outlet, without handpiece holder
and without filler cap)
Approx. 220 x 195 x 110
Weight (incl. handpiece)
Approx. 2,200 g
Handpiece dimensions (W x min. diameter x max.
diameter) in mm
120 x ~19 x ~24
Handpiece weight
Approx. 129 g
Ambient temperature (operation)
+10° - +35° C
Storage temperature
-5° - +40°C
Humidity
30% - 85 %
Permitted air pressure
800 hPa - 1060 hPa
Fuse
2 x fine fuses "2 A inert (type H)
IP Protection Class 30
Not protected against water
Protection against ingress of solid foreign objects
with a diameter > than 2.5 mm
Volume
45 dB +/- 15%
Subject to visual and technical changes.
