BAFANG DP C01.UART User Manual

2
DISPLAY MANUAL DP C01.UART
INTRODUCTION
• Name: Intelligent display HMI
• Model: DP C01.UART
• Scope: EN15194 electrical bicycle
• Appearance (as shown in the figure)
• Numbering on the back of HMI
Number on the middle of display back, num-
ber is divided into up row and down row (as
shown in the figure):
A. First line as below
DP C01.U 1.0
① DP C01.U : BAFANG Display model
② 1.0: Hardware version number
B. Second line as below
602E1S1230001
① 602: Wire length and connector model
850 M5.2, keypad250
② El: The internal identity code
③ S1230001: The production date is Jan.
23, 2018, and the serial number 0001.
please refer to <Instrument labelling
rules> for other detailed description,
the document number is BF-TS-753-
C0-02II.
• Display HMI P type wire label number rule
Number on the middle of P type label, num-
ber is divided into up row and down row
and QR code is at right side (as shown in the
below figure).
The first line:
DPC01E10101.0- Software version
The second line:
PD2528051305 - Parameter code
Content of QR code:
DPC01E10101.0
PD2528051305
DPC01.U 1.0
602E1S1230001
