5
BF-UM-C-DP C244-EN July 2022
USER MANUAL FOR DISPLAY
7.6 NORMAL OPERATION
7.6.1 Power ON/OFF
Press and hold (>2S) to power on the HMI, and the HMI begin to show the boot up LOGO.
Press and hold (>2S) again to power off the HMI.
If the automatic shutdown time is set to 5 minutes (set in function "Auto Off"), the HMI will be auto-
matically turned off within this set time, when it is not operated.
7.6.2 Power Assist Mode Selection
When HMI powers on, briefly press or to select the power assist mode and change the
output power. The lowest mode is E, the highest mode is B (which can be set). On the default is
mode E, number “0”means no power assistance.
Mode Color Definition
Eco green the most economic mode
Tour blue the most economic mode
Sport indigo the sport mode
Sport+ red the sport plus mode
Boost purple the strongest sport mode
