BAFANG DPC-10 Biktrix - Battery Status Indication; Battery Status Key; USB Charging

● Battery Status Indication
When the battery status is normal, a certain number of the battery LCD segments as well as
the border will light up according to the level of charge. If all 10 segments go blank and the
border starts blinking, the battery needs to be charged immediately.
● Battery status key
Number of
Percentage
Number of
Percentage
Number of
Charge in
Segments
Range
Segments
Range
Segments
Percentage
10
100% to 90%
6
50% to 60%
2
15% to 25%
9
80% to 90%
5
45% to 50%
1
5% to 15%
8
70% to 80%
4
35% to 45%
Border
0% to 5%
blinking
7
60% to 70%
3
25% to 35%
● When the display turns off, connect a USB
cable to the port on the display then the
display will turn on and charge. If the
display is turned on, only connect the USB
cable to the port to the display and display
begin charge. Maximum charge voltage is
5V, maximum charge current is 500mA
