6
CONSUMER MANUAL – DP C18.CAN
6 NORMAL OPERATION
6.1 Power ON/OFF
Press and hold (>2S) to power on the display, the display begin to operate. Press and hold
(>2S) again to power off the display.
If the "automatic shutdown" time is set to 5 minutes (it can be set in function "Auto Off"), the HMI
will be automatically turned off within this set time, When it is not operated. If password function is
turned on, than must input correct password to enter into the normal display interface.
6.2 Power assistance level selection
When HMI power on, briefly press or (<0.5S) to switch the assistance level (the number of
assistance level needs to be adapted to controller), The lowest level is Level 0, the highest Level is 5.
On the default is Level 1,“0”means no power assistance. The interface is as following:
6.3 Mileage mode and Speed mode
Briefly press (0.5s) to view the mileage and speed information.
1. System with torque sensor, circularly show the trip distance (TRIP)→ total distance (ODO) → max-
imum speed (MAX) → average speed (AVG) → remaining distance (RANGE) → energy consumption
(CALORIES) → time (TIME).
2. If system with a speed sensor, circularly show the trip distance (TRIP)→ total distance (ODO) →
maximum speed (MAX) → average speed (AVG) → remaining distance (RANGE) → time (TIME).
