65
Chapter 4 CARAVAN EQUIPMENT
a=Manual control (e.g. for ventilation)
Adjust desired output at the control knob.
b=Off (or automatic operation/heating with heaters Trumatic S
3002 K and S 5002 K)
c=Automatic operation (heating)
The output steadily adjusts to the respective heat emission of the heater.
The maximum output can be limited at the control knob, as required. The
regulating between this value and slow running is carried out
automatically.
Technical Data
Power supply: 12v
Power consumption: 0.3 to 1.0A
Air flow rate: Up to 180.000 litres/h
(with fan duct UR dia. 65mm)
Up to 205.000 litres/h
(with fan duct VR dia. 72mm)
