Chapter 4 CARAVAN EQUIPMENT
RM 6291L
Automatic ignition
1. Set energy selector switch (A) to Gas.
2. Press and hold rotary switch.
3. The ignition process is activated automatically, accompanied by a
ticking sound; the indicator lamp (D) will flash. Upon successful
ignition, the sound and the flashing will stop.
4. Keep rotary switch “B” depressed for another 10-15 seconds, then
release.
5. If the flame goes out, the ignition system will repeat the ignition
process automatically.
6. Adjust the temperature in the main refrigerator compartment using
rotary switch “B”.
All refrigerators, whether manual or automatic ignition, are equipped
ELECTROLUX REFRIGERATOR
MODEL RM 6291L & 6271
A= energy selector switch
B=gas/electric thermostat
D= “automatic ignition” indicator
