11
Control Switches (RH)
Right Handle Bar Switch
E. Starter Button : It operates the electric
starter when clutch lever is depressed with
t r a n s m i s s i o n i n a n y g e a r . I t i s
recommended to star t engine with
transmission in neutral.
Day Time Running Light Feature :
• Day Running light is provided above
headlamp. (as applicable to model)
• Day running light gets ON (High intensity)
when ignition switch turned to ON position.
• After headlight is turned to ON position,
intensity of DRL LED’s will get reduced.
: All lamps 'OFF'. DRL ON (High Intensity).
: Head lamp, Tail lamp, & Speedometer
lamps will glow. D R L r em a in s O N
(Low intensity)
F. Head Light Switch : It has 2 positions.
F
E
Igntion
Switch
ON
ON
DRL
ON High Intensity
ON Low Intensity
Light
Switch
OFF
ON
Head
Light
OFF
ON
Day Time
Running Light
(DRL)
To Next Page
