Control Switches (LH)
10
D
Left Handle Bar Switches
A. Hi / Lo Beam Switch : When headlight is
ON, High or Low beam can be selected
with the Hi / Lo switch. Hi beam indicator
light in speedo console will glow when
high beam is selected.
: High Beam : Low beam
B. Turn Signal Switch: When the turn signal
switch is turned to Left ( ) or Right ( ),
corresponding turn signals flash on & off.
To stop flashing, press the switch IN.
C. Horn Switch : ( ) Press horn switch for
sounding horn.
D. Pass Switch : ( ) Press the switch to
flash the head light in hi beam mode. It is
used to give signal to vehicles coming
from opposite side while overtaking.
A
B
C
