Bajaj Pulsar 150 CC DTS-i User Manual

CAUTION : While starting ensure that
engine kill switch is in ON ( ) position.
Keeping the kill switch in OFF position
Engine will not start.
Right Handle Bar Switches
E. Head Light Switch : It has 3 positions.
: All lamps 'OFF'.
: While engine running, Tail lamp and
Pilot lamps ‘ON’.
: While engine running, Headlamp, Pilot
lamp, Tail lamp, Meter lamps ‘ON’.
transmission in any gear. It is
recommended to start engine with
transmission in neutral.
G. Engine Kill Switch :The engine kill switch
is for emergency use. During emergency
move the engine kill switch to the ‘OFF’
( ) position.
F. Starter Button : It operates the electric
starter when clutch lever is depressed with
G
E
F
Location of Parts
7
CAUTION : Remove cover as described
above, otherwise the lugs may break.
Location of Parts
8
Removal of Side Cover LH or RH
• Insert key into cover lock & turn clockwise. &
pull ‘Side Cover’ out from the bottom.
• Pull front side (side towards Engine) of ‘Side
Cover’ to release Lug provided on ‘Side
Cover’ from hole (A) provided on ‘Fuel Tank’.
• Slide the ‘Side Cover’ forward (towards the
engine) to release slot provided on rear side
of ‘Side Cover’ from bracket with rubber cap
(B) provided on ‘Chassis’.
• Take out ‘Side Cover’.
Fitment of Side Cover LH or RH
• Match slot provided on rear side of ‘Side
Cover’ with bracket (B) provided on
‘Chassis’ and slide ‘Side Cover’ backward
(towards Tail lamp).
• Match Lug provided on front side of ‘Side
Cover’ with hole (A) provided on ‘Fuel
Tank’ and press ‘Side Cover’ inside.
• Match the lock plate of ‘Side Cover’
properly with bracket on ‘Chassis’ and
Lock.
CAUTION: Fit cover as described above
to ensure proper fitment.
B
A
