6
“Cranking ON and OFF duration” control:
• During Engine crank cycle cranking is allowed only for
fixed duration and in between successive cranks (in
case engine does not start) here is a cooling off
period.
• Cranking on-off duration control feature to avoid
battery discharge-
- 1st Crank ON (5 sec) & Disable for 2 sec.
- 2nd Crank ON (5 sec) & Disable for 2 sec.
- 3rd Crank ON (5 sec) & Disable for 10 sec.
After a gap of 10 sec cranking cycle continues.
• Headlight control on rpm – Headlamp will be turned
ON only at Engine running condition.
Steering cum Ignition Lock :
It has three positions
Lock : Steering locked. Ignition OFF.
OFF : Steering unlock. Ignition OFF.
ON : Steering unlock. Ignition ON.
To lock the steering :
Turn the handle bar to the left side. Push & Rotate the
key to “LOCK” Position & Remove the key.
Steering locking on handle position left hand side only.
To Unlock the Steering: Insert the key in steering cum ignition
lock. Push & Rotate it clockwise to "OFF" or "ON" position.
Key: A common key is used for 'Steering cum Ignition lock', 'Fuel
tank cap' & 'Rear Seat'.
