Tool Kit Location
Screw driver is kept in seat cowl RH as shown in photograph.
Spanner is kept in rider seat & fitted with tie band as shown
in photograph.
19
Removal of Pillion Seat
• Insert Key into lock (A).
• Turn the key clock wise.
• Lift front end of 'Pillion seat'
• Pull 'Pillion seat' toward front side.
• Take out 'Pillion seat'.
First Aid kit Location
• It is located on RH side of Seat Cowl below the ‘Pillion seat’
Screw Driver
Location
