398D003 Rev C 9 of 15
Step 10: Remove view screen cable screw on each side of the viewscreen, slightly lift up the
viewscreen and move sideways to clear cable bracket
Step 11: Lower control board and hang the top of the board off the lower screws. This
position will allow full access to the front seal panel hardware.
Step 12: Using a 7/16" ratchet or spin wrench, loosen and remove the locknut and washer
hardware from the upper viewscreen slides.
Top hardware
Bottom hardware
Upper viewscreen slide
