Baker BDINQ400 - Attaching Lifting Aids to the Cabinet; Step 1: Attach Lifting Aid Brackets; Step 3: Lift Cabinet to Table Top Height

398D003 Rev C 11 of 15
1/4-20 hexhead panel screws
ATTACHING THE LIFTING AIDS TO THE CABINET
Step 1: Attach the lifting aid brackets to each side of the cabinet by inserting the existing side
panel screws
Step 2: Attach the lifting bars to the brackets using 1/4-20 hex head screws
Step 3: For ergonomic reason lift the cabinet onto a lift table that can be raised to the InoqulA
table top height. Position the lift table with cabinet to the right side of the SA module and lift the
cabinet with four people over the SA table top while moving to the left. When the cabinet is in
the proper position remove the lifting aids from the each side.
1/4-20 hex head panel screws
