INFO (System Information sub-menu)
The System Information Menu displays various settings and identication of the particular system.
SSID (Software ID)
Displays the software ID number for the System.
MODL (System Model)
Displays the Model Number of the System.
SETP (Current Setup)
Displays the currently selected Conguration Setup Number.
Heater Voltage (Feature not used on CE rated systems.)
Displays the operating voltage congured for the heater.
Heater Wattage as Congured in Software (CE Systems Only.)
Displays a heater kilowatt rating as programmed into the control system software (1-3 or 3-6).
H _ (Heater Type)
Displays a heater type ID number.
SW _ (Dip Switch Settings)
Displays a number that represents the DIP switch positions of S1 on the main circuit board.
PANL (Panel Version)
Displays a number of the software in the topside control panel.
