Alarms Following alarms are available:
Sensor fail (FLS) see Table 4-5
Sensor fail is detected when measured value is 6% out of selected sensor characteristic.
Sensor fail is indicated by ##### symbol instead measured value.
Warning (WRN) see Table 4-5
When warning comes up, only alarm outputs and common warning output are closed.
Shut down (SD) see Table 4-5
When the shut−down alarm comes up, InteliLite opens outputs GCB CLOSE/OPEN, FUEL
SOLENOID, STARTER and PRESTART to stop the engine immediately. Alarm outputs and
common shutdown output are closed. Active or not reset protection disables start.
Table 4-5 Possible Warnings
Events specification Protection type Binary output available, Table 4-7.
Wrn Oil press WRN YES
Sd Oil press SD YES
Wrn Water temp WRN YES
Sd Water temp SD YES
Wrn Wtemp Low WRN YES
Wrn Fuel Level WRN YES
Sd Fuel Level SD YES
Analog inp IOM/PTM − Wrn WRN YES
Analog inp IOM/PTM − Sd SD YES
Binary input Configurable YES
Battery voltage <, > WRN YES
Battery flat SD YES
Start fail SD YES
ParamFail NONE NO
Vgen <, > SD YES
Vgen unbl SD YES
Fgen <, > SD YES
Igen unbl SD YES
Overload SD YES
RPM over SD YES
RPM under SD YES
TotalStop SD NO
PickupFault SD NO
Stop fail SD YES
WrnServiceTime WRN NO
ChrgAlternFail WRN YES
SprinklActive WRN NO
Wrn RA15 fail WRN NO
Sd IOM fail SD NO
