Balluff BOD 37M-LPR02-S115 - Technical Data; Accuracy Specifications; Sensor Characteristics; Ambient and Storage Conditions

www.balluff.com
Accuracy
The specifications are typical values for the
BOD 37M-LPR02-S115 at 24VDC and room temperature.
The sensor reaches its full accuracy after a minimum
switch-on time of 20minutes under constant ambient
conditions. The duration of warm-up depends on the
ambient conditions.
Accuracy (1Sigma/90% white,
XRite target)
±7mm
(Slow response time)
Repeat accuracy
(1Sigma/90% white, XRite
target)
1mm up to 10 m /
< 2mm up to 20 m
(slow response time)
Light type Laser red light, pulsed
Laser class according to
EN60825-1
2
Power/pulse width 1mW/4ns
Measuring range 0.2…20m (90% white)
0.2…8m (18% gray)
0.2…5m (6% black)
Wave length 658nm
Light spot size, typical 15mm at 10m
Resolution 1mm/16bits
Switching hysteresis
Adjustable
Factory setting
10…1000 mm
10mm
Ambient conditions
Ambient temperature T
a
–15…+50°C
(for cold start: ≥ –5°C)
Storage temperature –25…+70°C
Degree of protection per
IEC60529
IP67
(Required) UL Class2 power supply per
UL508
(Required) CDRH Per 21 CFR1003 and
1004
Reverse polarity protection Yes
Short-circuit protection Yes
Max. ambient light 40000 lux
Vibration (EN60068-2-6) 0.5mm amplitude,
10…55Hz frequency
per axis
Shock resistance
(EN60068-2-27)
11ms (30G)
6 shocks per axis
Moisture <90%, non-condensing
Supply voltage (external)
Supply voltage 24VDC±20%
Consumption ≤3W
Output
Analog output (linearity
error ±0.03% FS
V
,
±0.03% FS), scalable
Adjustable
Factory setting
0.2…10V/ 4…20mA
4…20mA
Load resistance R
L
Analog U
Analog I
≥ 1200Ω
≤ 100Ω
Switching output/Alarm
Factory setting
configurable (PNP, NPN,
Push-Pull, Q, Qneg)
Push-pull
Factory settings RS-485
Output mode
Terminating resistor
not active
off
Switchpoint 1/2
Adjustable
Factory setting
200…20000mm
500mm
Input
Multifunction input configurable
Mechanical
Connection type Connector
Connector M12×1, 8-pin
Housing material GD-ZN AL4
Dielectric strength 500V AC, 1min between
electronics and housing
Insulation resistance >17MΩ, 500V DC
between electronics and
housing
Active surface material PMMA
Dimensions 60 × 62.2 × 37mm
Weight ≤250g
Accessories
Connector
M12, straight, 8-pin, 5m (ordering code: BCC0995)
Technical data
No. 925867 EN
.
A16; Subject to modification.
6english
BOD 37M-LPR02-S115
Photoelectric Sensors – Laser Distance Sensor
