Configuration (continued)
5 english
Measuring range
RS-485
Scalabe Out
Factory Reset
Main Menu:
Reset
MIN Distance
MAX Distance
Scalabe Out:
SET
ESC
SET
>3 s
Save
Scalable output:
– Select the MIN und MAX
values for measurement
range.
– Reset: to restore the factory
setting range.
Factory settings
RS-485
Scalabe Out
Factory Reset
Main Menu:
YES
NO
Factory Reset:
SET
Save
Factory Reset: restore all factory settings
Information
Info
Main Menu:
Interface RS 485
Output stream:
MSB LSB
0 1 x x 0 0 1 0 1 0 1 0 1 1 0 1 1 1 1 1 1 0 0 1
Bin To Dig
Byte
count
1 2 3 4 Byte
count
5 6 7 8 9 10 Byte
count
11 12 13 14 15 16
11129 mm
Input command:
RS-485 Cmd 1 byte 2 byte 3 byte 4 byte 5 byte
Get Measure 0x40
hex
0x43
hex
Node N
hex
0x00
hex
0x01
hex
Keep
pressed for
longer than 1s and set
a number with
/
(200…20000mm).
