Balluff BSP-V Series User Manual

10 English
IO-Link interface
General device info
Baud rate COM 2 (38.4 kbaud)
Input of process data length 2 bytes
Minimum cycle time 5 ms
IO-Link version V1.1
SIO Mode Yes
SIO Mode
Balluff pressure sensors with IO-Link support both SIO
Mode and IO-Link Mode.
SIO Mode (standard IO mode)
In SIO Mode, the sensor works like a normal pressure
sensor with standard output signals.
Pin 4 (output 1) of the M12 plug is always a digital output.
An additional digital output or an analog output is available
on pin 2 (output 2), depending on the selected version.
IO-Link Mode (communication mode)
If the sensor operates subordinate to an IO-Link master,
then the pressure sensor switches to IO-Link communica-
tion mode. The IO-Link communication now runs via pin 4
of the M12 plug.
Process data
The process data length of the pressure sensor is 16 bits.
The switching statuses of the two switching outputs
(BCD1 and BCD2) are transmitted in the process data, as
well as the current measured value.
The 14 bits of the measured value are scaled correspond-
ing to the measuring range of the sensor.
15....2 1 0
Measured value
BDC2/Output 2 BDC1/Output 1
Measuring
range
Value range Multiplier
–1...2 bar –1000...2000 x0.001
–1...10 bar –100...1000 x0.01
0...2 bar 0...2000 x0.001
0...5 bar 0...5000 x0.1
0...10 bar 0...1000 x0.01
0...20 bar 0...2000 x0.01
0...50 bar 0...5000 x0.01
0...100 bar 0...1000 x0.1
0...250 bar 0...2500 x0.1
0...400 bar 0...4000 x0.1
0...600 bar 0...6000 x0.1
Error and event codes
Error codes
Error code Description
0x8011 Index not available
0x8012 Subindex not available
0x8023 Access denied
0x8030 Parameter value out of range
0x8033 Parameter length overrun
0x8034 Parameter length underrun
Event codes
Definition Event
codes
IO-Link
1.1
Event
codes
IO-Link
1.0
Device
status
Type
No malfunction 0x0000 0x0000 0 Notifica-
tion
General mal-
function.
Unknown error
0x1000 0x1000 4 Error
Process
variable range
overrun.
Process data
uncertain
0x8C10 0x8C10 2 Warning
Process
variable range
underrun.
Process data
uncertain
0x8C30 0x8C10 2 Warning
Pressure Sensors with IO-Link
BSP-B... /-V...
