Overview of adjustable parameters
Menu item Description Factory settings Own setting
Menu 1
SP1 / FH1
Switching point 1/
FH 1
80%
of the nominal pressure
Menu 2
rP1 /FL1
Return point 1 /
FL 1
75%
of the nominal pressure
Menu 3
SP2 / FH2
Switching point 2/
FH 2
80%
of the nominal pressure
Menu 4
rP2 /FL2
Return point 2 /
FL 2
75%
of the nominal pressure
Menu 5:2
dS1
Switching
delay time 1
0 sec
Menu 5:3
dr1
Return
delay time 1
0 sec
Menu 5:4
dS2
Switching
delay time 1
0 sec
Menu 5:5
dr2
Return
delay time 1
0 sec
Menu 5:6
ou1
Switching function
Output 1
Hno
Menu 5:7
ou2
Switching function
Output 2
Hno
Menu 5:8
uni
Units bar
Menu 5:13
dAP
Measure value damping 0 ms
Menu 5:14
code
Password 0000
Maintenance
Incorrect cleaning can cause irreparable dam-
age to the measuring cell.
Therefore never use pointed objects or com-
pressed air to clean the membrane.
The device is maintenance-free in principle. If required, the
housing can be cleaned with a damp cloth and mild
cleaning solution provided the device is switched off.
The membrane may become covered with deposits and
contamination, depending on the measuring material. If the
nature of the material is known, the operator must
define appropriate cleaning intervals. When the device is
decommissioned correctly, the membrane can be cleaned
carefully with a mild cleaning solution and a soft brush or
sponge.
Decommissioning
The measuring material may pose a risk to the
operator. Therefore always take appropriate
protective measures.
Always depressurize and disconnect the device from the
power supply before removing and check whether material
must be drained first!
Disposal
Residual material on the device may pose a risk
to the operator and a danger to the environ-
ment. Therefore always take
appropriate protective measures and dispose of
the device correctly.
The device must be disposed of according to European
Directives 2002/96/EC and 2003/108/EC (Waste Electrical
and Electronic Equipment). Equipment should be disposed
of separately from domestic waste!
Pressure Sensors with IO-Link
BSP-B... /-V...
