BTL5-A11-M/U_ _ _ _-P-SA167-S 32
Micropulse Linear Transducer in Profile Housing
2
english
Read this manual before installing
and operating the Micropulse trans-
ducer.
1.1 Proper application
The BTL5 Micropulse transducer is
intended to be installed in a ma-
chine or system. Together with a
controller (PLC) or a processor
(BTA) it comprises a position mea-
suring system and may only be
used for this purpose.
Unauthorized modifications and
non-permitted usage will result in
the loss of warranty and liability
claims.
1.2 Qualified personnel
This guide is intended for special-
ized personnel who will perform the
installation and setup of the system.
1 Safety Advisory
1.3 Use and inspection
The relevant safety regulations must
be followed when using the trans-
ducer system. In particular, steps
must be taken to ensure that should
the transducer system become
defective no hazards to persons or
property can result. This includes
the installation of additional safety
limit switches, emergency shutoff
switches and maintaining the per-
missible ambient conditions.
1.4 Scope
This guide applies to the model
BTL5-A11....P-SA167... Micropulse
transducer.
➥➥
➥➥
➥ Section 6 Versions (indicated on
product label) on page 7.
Contents
1 Safety Advisory ..................... 2
1.1 Proper application .................. 2
1.2 Qualified personnel ................ 2
1.3 Use and inspection ................ 2
1.4 Scope ..................................... 2
2 Function and
Characteristics ..................... 3
2.1 Characteristics ....................... 3
2.2 Function ................................. 3
2.3 Available stroke lengths and
magnets ................................. 3
3 Installation ............................ 3
3.1 Transducer installation ........... 3
3.2 Floating magnets.................... 4
3.3 Captive magnets .................... 5
3.4 Mounting angle ...................... 5
4 Wiring .................................... 6
5 Startup ................................... 7
5.1 Check connections ................ 7
5.2 Turning on the system ............ 7
5.3 Check output values .............. 7
5.4 Check functionality ................ 7
5.5 Fault conditions ...................... 7
5.6 Noise elimination .................... 7
6 Versions (indicated on
product label) ........................ 7
7 Technical Data ...................... 8
7.1 Dimensions, weights,
ambient conditions................. 8
7.2 Supply voltage (external) ........ 8
7.3 Outputs .................................. 8
7.4 Connection to processor ........ 8
7.5 Included in shipment .............. 8
7.6 Magnets (order separately) ..... 8
7.7 Accessories (optional) ............ 8
The following patents have been
granted in connection with this
product:
US Patent 5 923 164
Apparatus and Method for Auto-
matically Tuning the Gain of an
Amplifier
Emission tests:
RF Emission
EN 55011 Group 1, Class A
Noise immunity tests:
Static electricity (ESD)
EN 61000-4-2 Severity level 3
Electromagnetic fields (RFI)
EN 61000-4-3 Severity level 3
Fast transients (Burst)
EN 61000-4-4 Severity level 3
Surge
EN 61000-4-5 Severity level 2
Line-induced noise induced by
high-frequency fields
EN 61000-4-6 Severity level 3
Magnetic fields
EN 61000-4-8 Severity level 4
The CE Mark verifies
that our products meet
the requirements of
EC Directive
89/336/EEC (EMC Directive)
and the EMC Law. Testing in our
EMC Laboratory, which is accred-
ited by DATech for Testing Electro-
magnetic Compatibility, has con-
firmed that Balluff products meet
the EMC requirements of the fol-
lowing Generic Standards:
EN 50081-2 (emission)
EN 61000-6-2 (noise immunity)
