6.1 Accuracy
The specifications are typical values for BTL5-T… at
24VDC, and room temperature, with a nominal length of
500mm in conjunction with the BTL5-P-3800-2,
BTL5-P-4500-1, BTL5-P-5500-2
1)
BTL6-A-3800-2
1)
,
BTL6-A-3801-2
1)
, BTL5-F-2814-1S, BTL5-T-2814-1S,
BTL5-M-2814-1S or BTL5-N-2814-1S magnet.
The BTL is fully operational immediately, with full accuracy
after warm-up.
For special versions, other technical data may
apply.
Special versions are indicated by the suffix -SA
on the part label.
Position resolution 5 µm
Non-linearity ±30 µm
Hysteresis <1LSB
Reproducibility <2 LSB
Temperature coefficient
2)
<(6 µm+5ppm
× nominal length)/K
Velocity resolution 0.1mm/s
Velocity detectable max. 10m/s
6.2 Ambient conditions
Ambient temperature –40°C…+85°C
Storage temperature –40°C…+100°C
Relative humidity <90%, non-
condensing
Shock rating
Continuous shock
per EN60068-2-27
4), 5)
100g/6ms
100g/2ms
Vibration
per EN 60068-2-6
4), 5)
12g, 10…2000 Hz
Degree of protection per
IEC60529
when threaded together IP67
3)
6.3 Supply voltage (external)
Stabilized voltage
6)
20…28VDC
Residual ripple ≤0.5V
PP
Current draw (at24VDC)
7)
≤ 130mA
Inrush current ≤3A
Reverse polarity protection yes
Overvoltage protection Transzorb
protection diodes
Dielectric strength
(GND to housing)
500VDC
6.4 Control signals
RxD/TxD-N, RxD/TxD-P, Data GND per EN 50170
6.5 Magnet
Max. number of magnets 4
8)
6.6 Dimensions, weights
Nominal length 50…4000mm
Weight (depends on length) Approx. 1.4kg/m
Housing material Aluminum
6.7 Connection to the evaluation unit
Maximum length of the entire field bus cable is 1200m.
Cable twisted in pairs, shielded see Fig. 4-10.
1)
In the position range 0 to 20mm, the specified linearity limit can be
exceeded by ±100 µm.
2)
Nominal length 500mm, magnet in the middle of the measuring range
3)
For : Use in enclosed spaces and up to a height of 2000m above sea
level.
4)
Individual specifications as per Balluff factory standard
5)
Resonant frequencies excluded
6)
For : The BTL must be externally connected via a limited-energy
circuit as defined in UL61010-1, a low-power source as defined in
UL60950-1 or a class2 power supply as defined in UL1310 or UL1585.
7)
Depending on the load on VP (repeater, bus termination)
8)
Number dependent on nominal length (see section3.3)
6
Technical data
BTL5-T1 __ -M ____ -P-S103
Magnetostrictive Linear Position Sensor – Profile Style
