Balluff BTL5-T110-M0305-P-S103 - Table of Contents

www.balluff.com 3english
BTL5-T1 __ -M ____ -P-S103
Magnetostrictive Linear Position Sensor – Profile Style
1
Notes to the user 5
1.1 Validity 5
1.2 Symbols and conventions 5
1.3 Scope of delivery 5
1.4 Software 5
1.5 Approvals and markings 5
2
Safety 6
2.1 Intended use 6
2.2 General safety notes 6
2.3 Explanation of the warnings 6
2.4 Disposal 6
3
Construction and function 7
3.1 Construction 7
3.2 Function 7
3.3 Number of magnets 7
4
Installation and connection 8
4.1 Installing the BTL 8
4.2 Captive magnets 8
4.3 Floating magnets 9
4.4 Shielding and cable routing 10
4.5 Electrical Connection 11
4.5.1 Connecting the supply voltage, control and data signals 11
4.5.2 Connection example 11
5
Startup 12
5.1 Starting up the system 12
5.2 Operating notes 12
5.3 Default setting 12
5.4 Presettings 12
5.4.1 Station address 13
5.4.2 Bus termination 13
5.4.3 LED display for Profibus encoder profile 13
6
Technical data 14
6.1 Accuracy 14
6.2 Ambient conditions 14
6.3 Supply voltage (external) 14
6.4 Control signals 14
6.5 Magnet 14
6.6 Dimensions, weights 14
6.7 Connection to the evaluation unit 14
