11.6 Dimensions, weights
Rod diameter 10.2mm
Nominal length 25…7620mm
Weight (depends on
length)
Approx. 3kg/m
Housing material Stainless steel
Flange material Stainless steel
Rod material Stainless steel
Rod wall thickness 2mm
Housing mounting Flange with 6 holes
11
Technical data (continued)
BTL7-A/C/E/G5_ _-M_ _ _ _-J-DEXC-TA12
Magnetostrictive Linear Position Sensor – Rod Style
Type of protection “db” and “ta”
Flameproof enclosure
