Bambu Lab A1 with AMS lite - AMS lite Assembly (Connections)

⑤
②
③ ④
AMS lite Assembly
④ Inse long PTFE tubes into pos
3 and 4.
② Inse all four PTFE tubes into the
toolhead lament hub.
③ Inse sho PTFE tubes into pos 1 and 2.
① Put AMS lite to the right side of the A1
⑤ Clip the black data cable into the organizer.
Long
Sho
(The recommended distance between A1 and AMS lite is 50mm as shown in the diagram.)
Organizer
50mm
