Bambu Lab AMS lite - Page 17

① Slide in Purge Wiper unit into the slot at the end of the X-axis.
② Install the 1*M3-12 screw from the accesso box to x the Purge Wiper in place.
Install Purge Wiper
①
②
Push the toolhead to the middle of the rail, leaving enough space for purge wiper installation.
