SECTION 2
VESP211 Hardware
VESP211 Serial Servers are enclosed in a rugged panel mountable enclosure
and feature:
 LED indicators
 Power, Ethernet and serial connectors
 A recessed Reset (mode) switch.
Package Checklist
VESP211 Serial Servers are shipped with the following items included:
 VESP211 Serial Server Module
 Quick Start Guide
 CD with User Manual, Quick Start Guide
 DC Power Supply
VESP211 Serial Server Enclosures and Mounting
All VESP211 models are built into similar enclosures. Modules are panel
mountable.
Figure 2. Front View of the VESP211 Serial Server
