20. Specifications
Technical Specifications Controll-A-Door
®
S PanelPro
®
Power supply 230V - 240Va.c. 50Hz 230V - 240Va.c. 50Hz
Maximum door opening
Width:
Height:
Door Area:
Weight:
Door must be well balanced and
able to be operated by hand, as
per warranty conditions and AS/NZS
4505:2012
5500mm
2440mm
16.5m
2
100kg
4950mm
2440mm
13.5m
2
100kg
Minimum headroom 25mm 25mm
Short Term Peak force
Chain:
Belt:
10 Tooth Sprocket:
1200N
12 Tooth Sprocket:
1000N
800N
10 Tooth Sprocket:
800N
12 Tooth Sprocket:
650N
550N
Nominal force 150N (15kg) 150N (15kg)
Receiver type Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Receiver code storage capacity 8 X Tri-Tran
+
4-button Transmitters 8 X Tri-Tran+
™
4-button Transmitters
Coding System Tri-Tran
+
Technology Tri-Tran+
™
Technology
Coding type Non-linear encryption algorithm Non-linear encryption algorithm
Number of code combinations Over 100 billion random codes Over 100 billion random codes
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts)
Courtesy light Festoon style lamp 24volts 15 watts Festoon style lamp 24volts 15 watts
Network connectivity Network compatible,
(requires optional Smart Phone Control Kit
and SmartHub)
Network compatible,
(requires optional Smart Phone Control Kit
and SmartHub)
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn intermittently trigger the safety obstruction detection system.
