90 |
BEP CZone | Zeus Touch Operator Manual
CZone system overview options
Enables you to monitor all on board parameters including tank levels displayed in graphical,
percentage and volume remaining formats.
Shows control options and monitoring information.
Displays visual and audible alarms that can be set for high and low levels.
The CZone info panel
When the CZone is installed and configured, an additional CZone dashboard will be added to
the Instrument panels.
Vessel dashboard Navigation dashboard Angler dashboard CZone dashboard
You switch between a panel’s dashboards by tapping the left and right arrow symbols or by
selecting the dashboard from the menu.
Editing the CZone dashboard
You can customize CZone dashboard by changing the data for each of the gauges. Available
editing options will depend on the type of gauge and which data sources are connected to
your system.
