MODEL 200 UC REPLACEMENT PARTS
REVERSING “AUTOFEED PLUS” & FLOW DIVIDER MANIFOLD
# Part Number Description
1
900-3981-51 Retainer Nut & Sealing Ring
2
900-2909-55 Herschman Connector Only
3
900-3983-37 Solenoid Only
4
900-3982-43 Dual Solenoid Assembly
5
900-3984-25
Autofeed Plus & Flow Divider
Subplate
Torque Retainer Nut to a maximum of 4 to 6 ft.-lbs. (5 to 8 Nm) and install Loctite 243.
Over torque will cause damage and will also void warranty.
** Refer to check sheet for Autofeed Harness.
# Part Number Description
6
900-3946-88 Flow Divider Cartridge
7
900-3967-44 Seal Kit for Valve
8
** Autofeed Harness
4
5
6
2
3
1
2
3
1
To Next Page
