MODEL 2590
LOCATION NUMBER DESCRIPTION
1. SPD-02 Moving Parts...
2. SPD-03 Danger Lockout...
3. SPD-04 Flying Discharge Material...
4. SPD-15 Loader Arm
5. SPD-16 Do Not Hand Feed...
6. SPD-17 Do Not Run Or Operate...With Door/Compartment Open...
7. SPD-19 Entanglement
8. SPD-20 Flying Objects Stand Clear...
9. SPD-22 Emergency Shut Down Only
10. SPD-25 Stand Clear - Moving Conveyor
11. SPD-28 Do Not Insert Fingers
12. SPD-29 Do Not Climb or Reach Into Infeed Conveyor...
13. SPD-30 Do Not Sit, Stand, Lay, Climb...
14. SPD-32 Do Not Operate This Machine...
15. SPD-33 Do Not Work Under...
16. SPD-37 Lockout All Energy Sources...
17. SPD-62 Stay Clear of Tongue Jack/Stabilizer
18. ID-67 Made in USA
19. INST-01 Remove To Check Torque...
20. INST-02 Yoke Lock Hole
21. INST-03 Yoke Lock Bar
22. INST-04 Arrow
23. INST-10 Stabilizer Down / Up.
24. INST-12 Grease Daily (Arrow)
25. INST-44 Proposition 65
26. INST-45 For Parts and Service...
27. INST-48 Disc/Drum Lock Tube
28. INST-49 Disc/Drum Lock Pin
29. INST-53 Hydraulic Oil...Hydrex XV...
30. INST-75 Hydraulic Oil For “PT Tech” Clutch...
31. INST-90 Tongue Down / Up
32. INST-91 Lubricant For “Twin Disc” Hydraulic Clutch...
33. INST-92 Air Brake Release
34. INST-95 Electric Plug-In Schematic
35. INST-100 Lubricate Cutter Head Bearings...
36. INST-101 Canada Engine Decal
37. INST-102 Joystick Yoke Feedwheel
38. INST-147 Remote Start Procedure
39. INST-185 Yoke Lock Instructions
40. INST-222 Electrical Plug Diagram
41. INST-274 Remote Key Pad
DECALS
DECAL LOCATIONS - 2590
Modications and/or additions of decals to this list will happen.
Consult chipper dealer or manufacturer for most current decal package.
Some decals are for optional equipment. Decal locations may vary, these are general locations.
If any decals become damaged, replace immediately.
NOTICE
