43Copyright 6/18
MODEL 2590
5 & 6 Lug Hubs (1/2” - 20 Studs) ........................ 90 - 120 ft.-lbs. Torque (122 - 163 Nm)
8 Lug Hubs (1/2” - 20 Studs) .............................. 90 - 120 ft.-lbs. Torque (122 - 163 Nm)
8 Lug Hubs (9/16” - 18 Studs) ............................ 110 - 120 ft.-lbs. Torque (149 - 163 Nm)
8 Lug Hubs (5/8” - 18 Studs) .............................. 190 - 210 ft.-lbs. Torque (258 - 285 Nm) (Cone Nut)
8 Lug Hubs (5/8” - 18 Studs) .............................. 275 - 325 ft.-lbs. Torque (373 - 441 Nm) (Flange Nut)
8 Lug Hubs (22mm x 1.5 Studs) ......................... 450 - 500 ft.-lbs. Torque (610 - 678 Nm) (Flange Nut)
10 Lug Hubs (3/4” - 16 Studs) ............................ 450 - 500 ft.-lbs. Torque (610 - 678 Nm)
(Consult axle manufacturers manual shipped with each machine for specic axle-stud-wheel combination lug nut torques.)
KEEP LUG NUTS PROPERLY TIGHTENED, CHECK NEW UNIT BEFORE OPERATION, CHECK
AGAIN AFTER 20-25 MILES (32-40 km) AND REGULARLY CHECK AT LEAST WEEKLY.
BASIC WHEEL TORQUE REQUIREMENTS (per mfg.)
MAINTENANCE
BOLT TORQUE CHART
(THESE TORQUES ARE BASED ON DRY, CLEAN THREADS)
DESCRIPTION BOLT SIZE TORQUE (FT.-LBS.) TORQUE (Nm)
Chipper Bearing Bolts 1” - 8 NC 500 678
Drum Bearing Housing Bolts 1” - 8 NC 325 441
Chipper Drum Bolt-On Hub 7/8” - 9 NC 350 475
Drum Keyless Taperlock Bushing 170 230
Knife Bolts - Babbitt Style 5/8” - 18 NF 210 285
Knife Holder Bolts 3/4” - 10 NC 250 339
Anvil 3/4” - 10 NC 250 339
Belly Band Bolts 5/8” - 11 NC 200 271
Feedwheel Bearing Bolts 5/8” - 11 NC 212 287
Feedwheel Bearing Set Screws 3/8” - 24 NF 20 27
Grip-Tight Feedwheel Bearing Set Screws 2 3
Engine Hold Downs 350 475
Sheave Bushing “J” 5/8” - 11 NC 135 183
Sheave Bushing “M” 3/4” - 10 NC 225 305
Sheave Bushing “N” 7/8” - 9 NC 300 407
Sprocket Bushing “Q1” 3/8” - 24 NF 30 41
Sprocket Bushing “R1” 3/8” - 24 NF 30 41
Valve Solenoid Retainer Nut 4 - 6 5 - 8
Hitch Mount Bolts 7/8” - 9 NC 350 475
Before tightening bolts be sure you have the correct size bolt for the correct amount of torque.
Use only factory approved knives and hardware.
