Bandit
93Copyright 6/18
MODEL 2590
KNIFE BOLTS MUST BE INSTALLED THROUGH KNIFE AS SHOWN.
NOTICE
Torque Knife Bolt to 210 ft.-lbs. (285 Nm)
Torque Knife Holder Bolt to 250 ft.-lbs. (339 Nm) with Loctite 243 (Blue)
LOCATION PART NUMBER DESCRIPTION
LOCATION PART NUMBER DESCRIPTION
1. 500-0001-16 Knife Saver Kit
2. 900-9901-65 File For Knife Saver Kit Only
3. 900-9914-29 Replacement Blades For Knife Saver
4. 900-9914-24 Knife Changing Gloves
KNIFE SAVER KIT
4
1
CHIPPER KNIFE & HARDWARE
BOLT IN STYLE KNIFE
Knife Holders, Knife Holder Bolts, & Knife Gauges for
other chip sizes available upon request.
1. 938-300005 Knife Holder
2. 900-4914-30 3/4”-10NC x 2 1/4” SHCS Knife Holder Bolt
3. 900-9902-27 Knife
4. 900-4901-32 5/8” Washer
5. 900-4913-99 5/8”-18NF x 2” Gr 8 Hex Head Bolt
To Next Page
