10
Power Rating: 8 ohms
4 ohms
30 Watts
55 Watts
Number of Channels 12
Current (peak to peak) 16 Amps
Dynamic Headroom 1.0dB
Total Harmonic Distortion (THD) 0.09% at 1kHz
Frequency Response 5 Hz - 45 kHz
S/N (A-Weighted) 95 dB
Input sensitivity 0.55 Volts
Input Impedance 33.2 k ohms
Dampening Factor 80
Slew Rate 14 V / µsec
Voltage Gain 28
Line Voltage 120/220/240 VAC switchable
Level Controls Dual
Control Input/Output Yes
Minimum Control Input Voltage 5 VDC @ 1 mA
Output Connector Max Wire Gauge 12 gauge
Dimensions (Cut Out Dimensions)
Height
Width
Length
4” (4.125”)
17” (17.125”)
15.25” (15.38”)
Weight (in lbs.) 22
Power Consumption 360 Watts
Replacement Fuse (Main AC) 8A / 250 Volt Slow Blow
*Specifications and design are subject to change at any time without notice.
