5. Status indicators
- Displays current status of the processors audio processor. Indicators have been supplied
to show when the DSP is decoding Dolby Digital ‘
Digital
’, Dolby Pro Logic ‘
Pro Logic
’, or DTS audio.
There is an indicator to show the input to the S/PDIF digital receiver is 96kHz 24 bit data ‘
96/24’
or an analog
input that is being sampled using 96kHz/24bits. Finally, there is an indicator to show processed audio is sourced
from the selected analog input ‘
Analog
’. See MODE OPERATION
6. Display
- The processor display is a 16 character alphanumeric fluorescent display. Displays current status of
processor and any changes being performed.
